The DA45-5 Articulated Dump Truck, brought to the market by DEVELON (formerly Doosan), stands out as a powerful and versatile machine tailored for the demanding tasks in construction, mining, and quarrying operations. With an increased payload capacity, advanced technology for operator comfort, and enhanced performance metrics, the DA45-5 is engineered to deliver productivity and efficiency on challenging terrains. Here's an in-depth look at its features and specifications:
General Specifications:
- Payload: Boasts an impressive maximum payload of 41 metric tons (45.2 US tons), offering significant capacity for bulk material transport.
- Gross Vehicle Weight: Fully loaded, it has a gross weight of about 71.1 metric tons (78.4 US tons).
Performance Features:
- Engine: Powered by a Scania DC13 diesel engine, which provides 500 horsepower (373 kW) at 2100 rpm. It's compliant with Tier IV Final emissions standards, using SCR (Selective Catalytic Reduction) technology for cleaner exhaust.
- Transmission: Equipped with a ZF 8-speed forward and 4-speed reverse automatic transmission, ensuring smooth transitions and optimal performance across various terrains.
- Drive System: Features a full-time 6x6 drive system with limited slip differential for superior traction and stability, particularly in off-road conditions.
Structural and Mobility:
- Frame: The articulated design offers excellent maneuverability with a turning radius of approximately 30 feet (9.14 meters), crucial for navigating tight job sites.
- Suspension: Employs a self-leveling hydro-gas front suspension system, which significantly improves ride quality and load retention over uneven ground.
- Tires: Fitted with 29.5 R 25 radial tires, optimized for durability and traction in harsh conditions.
Operator Comfort and Safety:
- Cab: The operator's cab prioritizes comfort with climate control, a heated air suspension seat, and a low-noise environment. It includes a high-resolution monitor for machine diagnostics and operation metrics.
- Safety: Certified with ROPS/FOPS standards, ensuring protection from rollovers and falling objects. Enhanced visibility is provided by large windows and an optional rearview camera system.
Additional Features:
- Braking: The truck features an advanced braking system with oil-cooled disc brakes and an integrated retarder for controlled downhill travel, reducing brake wear.
- Serviceability: Designed with ease of maintenance in mind, with centralized service points and access to diagnostic tools via DEVELON's telematics system, known as MY DEVELON.
Usage and Applications:
- The DA45-5 is exceptionally suited for heavy-duty hauling tasks in mining, large-scale construction projects, or quarrying where moving large volumes of material efficiently is key. Its design allows for operation in diverse environmental conditions, from wet to dry, ensuring versatility.
The DA45-5 reflects DEVELON's commitment to innovation in articulated dump trucks, combining high performance with user-friendly operation and maintenance, making it a top choice for professionals requiring heavy-duty hauling capabilities with an emphasis on safety and efficiency.
