The HA46 RTJ O by Haulotte is an engine-powered articulating boom lift designed for flexibility in challenging construction and maintenance environments. It offers a blend of reach, safety, and performance, making it suitable for indoor and outdoor applications where maneuverability around obstacles is necessary.
Performance:
- Lift Height: Provides a platform height of 46 feet (14 meters), giving a working height of 52 feet (15.8 meters).
- Horizontal Reach: Extends up to 27 feet 3 inches (8.3 meters), allowing for access to areas far from the base.
- Up and Over: Features an up-and-over capability of 23 feet 7 inches (7.2 meters), useful for navigating around barriers like building features or machinery.
Power and Efficiency:
- Powered by a 48 hp Kubota D1105-E4B diesel engine, which is compliant with Tier 4 Final emissions standards, ensuring high performance with reduced environmental impact. The fuel tank capacity is approximately 16 gallons (60 liters).
Capacity and Platform:
- The platform can carry up to 550 pounds (250 kg), providing space for one or two workers along with tools or materials. The platform dimensions are roughly 5 feet by 2 feet 7 inches.
Terrainability:
- Equipped with 4-wheel drive and an oscillating axle, this lift can handle slopes up to 45% gradeability, making it adept for rough terrain. It also features non-marking tires for indoor use if needed.
Additional Features:
- Haulotte Activ’Shield Bar: An option for preventing crushing hazards by stopping the machine if the operator is trapped against the bar.
- Haulotte Activ'Lighting System: Enhances safety for loading and unloading in low-light conditions.
- Haulotte Stop Emission System: Automatically shuts down the engine after inactivity, reducing fuel consumption and emissions.
Operational Benefits:
- The HA46 RTJ O is designed for ease of use with fully proportional controls for smooth, precise movements. Its compact design allows for excellent maneuverability, and the 360-degree continuous rotation ensures comprehensive reach around the base.
Dimensions and Transport:
- In its stowed position, the lift measures approximately 21.5 feet (6.55 meters) in length, 7 feet 9 inches (2.36 meters) in width, and 7 feet 11 inches (2.41 meters) in height, making it manageable for transportation on standard flatbed trailers, although its size should be considered for site-to-site movement.
